S-W336 is used for processing single conductors and inner conductors of multi-core cables. The pneumatically operated S-W336 stripping machine excels with its compact design, fast cycle times and infinite settings for onductor diameters, stripping -and pull-off lengths.S-W336 is a pneumatic wire and cable stripping machine and the perfect solution for stripping discrete wires and small multi-conductor cables up to 3.2 mm O.D. The compact machine strips lengths up to 20 mm. S-W336 satisfies the ever tougher quality requirements in wire processing. High precision and short cycle times for full and partial pull-off are characteristic of S-W336 equipped with V-blades (blades can be customized). Operating strictly electrically, the portable machine can be used anywhere a power socket is available. The ease of operation and the short cycle times make S-W336 ideal for a great diversity of products made in small to medium quantities. This machine has lots of advantages such as Outstanding ease of operation, Light and portable, Extremely short cycle times, No blade change necessary, Strips very short cables, Simple machine operation, Robust & reliable.



Mini Wire Stripping Machine.

     Contact :
   Tel: +66 02-504-0591
   Hp:  +66 081-852-4529

   E-Mail:   sales@sonictech.co.th


Products List

Wire Stripping Machine.
 1. Wire Stripping Cutting Machine.
 2. Enamel Stripping Machine.
 3. Pneumatic Wire Stripping  Machine.
 4. Coaxial Cable Strippng  Machine.
Tape and Tube Cutting machine.
 1. Tape and Flat Tube Cutting Machine.
 2. Tube Cutting Machine.
Terminal Crimping Machine..
 1. Full AutoTerminal Crimping Machine.
 2. Semi Auto terminal Crimping Machine.
 3. Terminal Crimping Tools.
Dot Marking Machine.
 1. Dot Peen Marking Machine.
 2. Portable Dot Peen Marking Machine.
Force Gauge.
 1. Electric-vertical-test-stand .
 2. Wire Terminal Force Gauge.
 3. Force Gauge.
Another Products.
 1. Auto Screw Feeder machine.


Mini Strip

Destription: Mini Wire Stripping Machine
Model: S-336

  • Wire Size Range: 0.03mm² – 2.08mm² (AWG32- AWG 14)
    Max. Outer Cable Diameter: 3.2 mm (0.12")
    Stripping Length Increments:
    Full strip: 0.5 mm (0.019")
    Pull-off / partial pull-off length: 2 mm (0.078")
    Precision of Diameter Setting: 0.01 mm (0.001")
    Max. Stripping Length: 20 mm (0.78") (1-20mm)
    Circle Time: approx. 0.3 s
    Dimensions (L × W × H): 265 x 70 x 135 mm (10.4"x 2.8"x 5.3")
    Net Weight: 2.0 kg (4.4 lbs.)
    Gross Weight: 2.4 kg (5.3 lbs.)
    Air Pressure: 0.5Pa-0.8P

S-W336S-W336S-W336



Available Material: Discrete Wire, Solid Wire, Stranded Wire, Single Conductor Cable, Wire, Cable, Rubber, PUR, PVC, Teflon®, Tefzel®, etc.
