    Product Details.  Model: M-10
Features:
 The machine is driven by dual- action standard cylinder, which has advantage of hight efficiency and quality in crimping force and speed. The machine first for many kinds of terminal. The die set are interchangeable with out manual crimping tools, we provide all kind of die set accoding to your terminal.

Specification.
  The range og applicatoin : non- insulated terminal Max. 16mm2, insulated terminal tube type.
  Terminal Max : 35mm2.
  Crimp force : 13 Kn.
  Air pressure : 0.4~1 Mpa.
  Dimension : 260mm x 120mm x 140mm.
  Weight : 4 Kg.
    M-10 M-10 M-10 M-10


  • Other requirement available machines model and spec your request, Please contact for more infomation and detail.
