Full Auto Terminal Crimping +Vibration Sysytem Machine

Terminal Strip and CrimpingMachine
Products List

Wire Stripping Machine.
 1. Wire Stripping Cutting Machine.
 2. Enamel Stripping Machine.
 3. Penumatic Wire Stripping  Machine.
 4. Coaxial Cable Strippng  Machine.
Tape and Tube Cutting machine.
 1. Tape and Flat Tube Cutting Machine.
 2. Tube Cutting Machine.
Terminal Crimping Machine..
 1. Full AutoTerminal Crimping Machine.
 2. Semi Auto terminal Crimping Machine.
 3. Terminal Crimping Tools.
Dot Marking Machine.
 1. Dot Peen Marking Machine.
 2. Portable Dot Peen Marking Machine.
Force Gauge.
 1. Electric-vertical-test-stand .
 2. Wire Terminal Force Gauge.
 3. Force Gauge.
Another Products.
 1. Auto Screw Feeder machine.












Product Details. Model: 1800S
Features:
The wire stripping and crimping machine is specially designed forthe process of stripping the wire and then crimping it. It reduces a processing step to operating function, thus it's a ideal solution for processingthe inner cores of multi conduct cable.


Specification :
Available Wire Size : AWG19- AWG 30
Steipping Length : 1.0-10.0mm
Max : Crimping Force : 1500Kg(1.5 Tons)
Stroke Distance : 30mm
Out put : 1000-2000Pcs/Hrs
Air Pressure :0.5-0.7Mpa
Power supply : 220V/50Hz
Net Weight : 50 Kg
Dimension : 400x250220x460mm


  • Other requirement available machines model and spec your request, Please contact for more infomation and detail.
