Product Details. Model: R2
Features:
The automatic crimping machine is for the process of both side stripping and crimping. It comprises wide applications capable to fit verticaland horizontal crimping dies of any brands. Also it supports many optional devises such as conveyor belt, wire feeding unit, vibration plate etc.

Specification
:

Wire Size: AWG 16~AWG 30
Cutting Leangth : 50~9999.9mm
Stripping Lenght : Head Max. 10mm, End Max14mm
Tolerance : ±0.1mm
Crimping Force : 1.5~2.0Tons
Stroke : 30mm (40mm is Customizable)
Motor : 550W
Display : 5.7 inch touch screen
Speed : 4000 pcs/ Hr
Air Pressure : 0.4Mpa~0.6Mpa
Pow : 220V/50Hz
Gross Weight : 250Kg
Dimension : 110x700x1650mm

  • Other requirement available machines model and spec your request, Please contact for more infomation and detail.
