Havy Duty Wire Stripping and Cutting Machine.

S-09H


Products List

Wire Stripping Machine.
 1. Wire Stripping Cutting Machine.
 2. Enamel Stripping Machine.
 3. Pneumatic Wire Stripping  Machine.
 4. Coaxial Cable Strippng  Machine.
Tape and Tube Cutting machine.
 1. Tape and Flat Tube Cutting Machine.
 2. Tube Cutting Machine.
Terminal Crimping Machine..
 1. Full AutoTerminal Crimping Machine.
 2. Semi Auto terminal Crimping Machine.
 3. Terminal Crimping Tools.
Dot Marking Machine.
 1. Dot Peen Marking Machine.
 2. Portable Dot Peen Marking Machine.
Force Gauge.
 1. Electric-vertical-test-stand .
 2. Wire Terminal Force Gauge.
 3. Force Gauge.
Another Products.
 1. Auto Screw Feeder machine.

Model
S-09K
Core Cross-Section Range: 0.1 ~ 16mm2 (AWG30 ~ AWG5)
 0.3 ~ 70 mm2

0.1 - 10.0mm2

Max Conduit Diameter:
Φ10mm
Φ18mm
Ø10.0mm
Cutting Length:
5 ~ 20001mm
99999mm
9999mm
Stripping Length:
Head 0~99mm, End 0~70mm
Head 0~99mm, End 0~99mm
Head 0~99mm, End 0~70mm
Max. Middle Stripping Section:
13 places
13 places
11 mm
Cutting Tolerance:
±(0.002×L)  （L=Cutting Length)
Speed:
2000pcs/hour
3000~8000pcs/hour
Display
English LCD  dispaly
Drive Mode:
4 Drives
8 wheels drive
4 Drives
Blade
Hard tungsten steel
Appropriate Wire:
PVC, Teflon, glass wire
Power Supply:
220V/50Hz   110V/60Hz
Power Rating:
450W
1000W
220W
